C503B-ABN-CW0X0341

Overview

The C503B-ABN-CW0X0341 is an amber light-emitting diode from the Cree LED series, designed for through-hole mounting in a standard 5 mm (T-1 3/4) radial package. It features two leads and emits light at a dominant wavelength of 591 nm. The component operates with a forward voltage of 2.1 V and provides reliable signal indication. Key electrical specifications include a maximum forward current rating of 50 mA and a maximum power dissipation capacity of 130 mW. The device utilizes a clear lens to ensure optimal light transmission.

Feature Summary

• Amber color emission at 591 nm for distinct visual signaling
• Through-hole radial construction in a 5 mm T-1 3/4 package
• Clear lens design for efficient light transmission

Applications

• General-purpose electronic status indication
• Panel-mounted signal lights
• Low-power indicator circuits

Procurement Notes

Verify the specific suffix configuration against official datasheets to confirm exact optical and electrical characteristics. Ensure compatibility with existing PCB footprints for the 5 mm radial package. Confirm RoHS compliance requirements for the target assembly. Cross-reference manufacturer part numbers to avoid substitution errors during procurement.

Selection Notes

Select this component when a 591 nm amber wavelength is required for clear visibility. The 2.1 V forward voltage suits low-voltage logic interfaces. Consider the 50 mA current limit for drive circuit design. The T-1 3/4 package offers mechanical stability for panel applications requiring robust mounting.

Part Context

This part belongs to the Cree LED C503B series, which focuses on high-reliability discrete LEDs. The series supports various colors and wavelengths within the 5 mm form factor. It targets industrial and commercial equipment needing durable visual indicators. The product line emphasizes consistent performance across operating temperatures.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
