C503B-ABN-CW0Z0251

$0.16

Description：LED AMBER CLEAR 5MM ROUND T/H
Series：-
Mfr：Cree LED
Package：Bulk

SKU:1e6616aae33f Category: LED Indication - Discrete Brand: Cree LED

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LED AMBER CLEAR 5MM ROUND T/H
Series：-
Mfr：Cree LED
Package：Bulk
Color：Amber
Configuration：Standard
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：7500mcd
Lens Style：Round with Domed Top
Lens Size：5.00mm Dia
Voltage - Forward (Vf) (Typ)：2.1V
Current - Test：20mA
Viewing Angle：23°
Mounting Type：Through Hole
Wavelength - Dominant：591nm
Wavelength - Peak：-
Features：-
Package / Case：Radial
Supplier Device Package：5mm Round
Size / Dimension：-
Height (Max)：13.30mm

Download product information

C503B-ABN-CW0Z0251

Overview

Cree LED C503B-ABN-CW0Z0251 is a through-hole amber light-emitting diode in the 5 mm (T-1 3/4) package. It features a clear oval lens and emits at a dominant wavelength of 596 nm with a luminous intensity of 12 cd. The component operates with a forward voltage of 2.6 V and a maximum power dissipation of 130 mW. It has a viewing angle of 23 degrees and supports a maximum forward current of 50 mA.

Feature Summary

Provides high visibility with superior light output for excellent readability in sunlight
Ensures dependable performance over long periods with extremely stable light output
Constructed with advanced optical-grade epoxy for high temperature and moisture resistance

Applications

Electronic Signs & Signals (ESS)
Motorway Signs
Variable-Message Sign (VMS)
Advertising Signs
Petrol Signs

Procurement Notes

Verify the specific part number against official Cree LED documentation to confirm exact electrical parameters and physical dimensions. Ensure compliance with RoHS standards and check for any recent product change notices or design specifications that may affect integration. Confirm availability status directly with authorized distributors as stock levels fluctuate.

Selection Notes

Select this component for applications requiring reliable amber indication with high brightness. The 5 mm T-1 3/4 package offers standard mounting compatibility. Consider the 23-degree viewing angle and 12 cd intensity for optimal visibility requirements. Verify thermal management needs given the 130 mW power dissipation limit.

Part Context

The C503B series represents a line of round LEDs designed for outdoor signal and sign applications. These components utilize advanced optical-grade epoxy to withstand harsh environmental conditions. The series includes various colors and wavelengths, providing flexibility for different signaling needs while maintaining consistent quality and durability standards.
