C535A-WJN-CS0V0151

Overview

The C535A-WJN-CS0V0151 is a single-color LED from the Cree LED C535A series, designed for through-hole mounting in a 5 mm (T-1 3/4) radial package. It emits warm white light with a correlated color temperature of 2700K and features a clear, round lens. The component operates at a typical forward voltage of 3.2 V and has a maximum power dissipation of 120 mW. It offers a viewing angle of 25 degrees and is RoHS compliant.

Feature Summary

• Emits warm white light with a 2700K color temperature
• Utilizes a 5 mm T-1 3/4 through-hole radial package
• Features a clear, round lens design

Applications

• General illumination indicators
• Decorative lighting applications
• Low-power signaling devices

Procurement Notes

Verify the specific suffix codes against official Cree LED documentation to confirm exact binning and optical characteristics. Ensure that the selected variant matches the required thermal management and current drive specifications for the intended application environment.

Selection Notes

Select this component when a standard 5 mm through-hole form factor is required for warm white indication. Consider the 25-degree beam angle and 3.2 V forward voltage drop during circuit design to ensure proper driver compatibility and optical coverage.

Part Context

This part belongs to the C535A family, which provides high-brightness single-color LEDs in a traditional 5 mm package. The series is optimized for applications requiring reliable through-hole mounting solutions with consistent chromaticity and luminous intensity performance.

Replacement Considerations

Consult official Cree LED substitution guides for direct equivalents. Verify pinout compatibility and thermal resistance parameters before replacing with alternative manufacturers' components.
