C535A-WJN-CS0V0231

Overview

The C535A-WJN-CS0V0231 is a Cree LED amber light-emitting diode featuring a 5mm (T-1 3/4) through-hole package. It operates with a forward voltage of 2.1 V and a maximum forward current of 30 mA. The component emits at a peak wavelength of 605 nm with a viewing angle of 30 degrees. It provides an optical intensity of 18 cd and has a maximum power dissipation rating of 120 mW.

Feature Summary

• Amber emission color optimized for high visibility applications
• Standard 5mm T-1 3/4 through-hole form factor for easy integration
• Wide 30-degree viewing angle for broad illumination coverage

Applications

• Indicator lights in electronic equipment
• Traffic signal assemblies
• Automotive instrument clusters

Procurement Notes

Verify the specific binning codes for chromaticity and luminous intensity to ensure compliance with project requirements. Confirm RoHS compliance status and lead times directly with authorized distributors, as availability varies by region and production cycle.

Selection Notes

Select this component when a standard 5mm through-hole amber LED is required. Ensure circuit design accommodates the 2.1 V forward voltage drop. Consider thermal management if operating near the maximum 30 mA continuous current limit.

Part Context

This part belongs to the Cree LED general-purpose indicator series. It utilizes established phosphor conversion technology for stable amber output. The 5mm package ensures compatibility with legacy PCB layouts and manual assembly processes common in industrial control panels.

Replacement Considerations

Cross-reference with other 5mm amber LEDs from manufacturers like Osram or Everlight. Verify pinout orientation and mechanical dimensions match existing footprints before substitution.
