C5S-26.000-16-1010-R

Crystals Overview

The C5S-26.000-16-1010-R is a surface-mount crystal oscillator manufactured by Aker Technology Corp. It operates at a nominal frequency of 26 MHz with a load capacitance of 16 pF and an equivalent series resistance of 25 Ohms. The component features a frequency stability and tolerance of ±10 ppm. It is housed in a compact 4-SMD, No Lead package suitable for automated assembly processes.

Crystals Feature Summary

• Surface-mount design for automated PCB assembly
• High frequency stability within ±10 ppm tolerance
• Standard 16 pF load capacitance configuration

Crystals Applications

• General-purpose clock signal generation
• Microcontroller timing circuits
• Communication interface synchronization

Crystals Procurement Notes

Verify the complete part number including suffixes to ensure correct packaging and temperature range specifications. Confirm RoHS compliance status through official manufacturer documentation prior to procurement. Cross-reference datasheet parameters against system requirements to validate electrical characteristics and physical dimensions.

Crystals Selection Notes

Select this component when a 26 MHz reference with ±10 ppm stability is required. Ensure the application circuit provides the specified 16 pF load capacitance for accurate frequency operation. Verify that the operating temperature range of -20°C to 70°C meets environmental constraints.

Crystals Part Context

This part belongs to the C5S series of surface-mount crystals from Aker Technology. The series offers various frequency options and package sizes designed for space-constrained electronic applications requiring reliable timing references.

Crystals Replacement Considerations

Direct substitutes include other 26 MHz SMD crystals with identical 16 pF load capacitance and ±10 ppm stability. Verify pin compatibility and mechanical footprint before substitution.
