Product Detailed Parameters
- Description：LED AMBER CLEAR 5MM OVAL T/H
- Series：Screen Master®
- Mfr：Cree LED
- Package：Tape & Box (TB)
- Color：Amber
- Configuration：Standard
- Lens Color：Amber
- Lens Transparency：Clear
- Millicandela Rating：1885mcd
- Lens Style：Oval with Domed Top
- Lens Size：5.10mm x 3.70mm
- Voltage - Forward (Vf) (Typ)：2.1V
- Current - Test：20mA
- Viewing Angle：100° x 40°
- Mounting Type：Through Hole
- Wavelength - Dominant：590nm
- Wavelength - Peak：-
- Features：-
- Package / Case：Radial
- Supplier Device Package：5mm Oval
- Size / Dimension：-
- Height (Max)：8.50mm
Download product information
Overview
The C5SMF-AJE-CS0V0252 is a standard through-hole oval LED manufactured by Cree LED. It emits amber light with a peak wavelength of 591 nm and operates at a forward voltage of 2.1 V under a 20 mA forward current. The component features a viewing angle of 100 degrees by 40 degrees and delivers a luminous intensity of 2100 mcd. Housed in a T-1 3/4 (5 mm) package, it has physical dimensions of 5.1 mm in length, 3.7 mm in width, and 7 mm in height. The device supports an operating temperature range from -40 °C to +95 °C.
Feature Summary
- Oval-shaped radiation pattern designed for wide-angle visibility
- High luminous intensity output suitable for clear indication
- Through-hole mounting configuration for standard PCB integration
Applications
- Variable-message signs
- Passenger-information displays
- Industrial status indicators
Procurement Notes
Verify the specific suffix codes against official Cree LED documentation to confirm exact optical and electrical characteristics. Ensure compatibility with existing board layouts regarding the T-1 3/4 package dimensions. Confirm availability status as product lines may undergo discontinuation or revision without immediate notice.
Selection Notes
Select this component when a wide horizontal viewing angle is required for signage applications. The amber color and high intensity make it suitable for environments needing high contrast visibility. Verify thermal management requirements given the maximum operating temperature limit of 95 °C.
Part Context
This part belongs to the Screen Master 5-mm Oval LED family from Cree LED. These devices are engineered specifically for display applications requiring broad radiation patterns. The series emphasizes high luminous intensity within a compact oval footprint to optimize visibility in public information systems.
Replacement Considerations
Consult official Cree LED substitution guides for verified equivalents. Generic replacements may not match the specific 100x40 degree viewing angle or 591 nm wavelength requirements.
