C5SMF-BJE-CT34Q4T1

Overview

The C5SMF-BJE-CT34Q4T1 is a blue discrete LED from the Screen Master series by Cree LED. It features a 5mm oval dome lens with clear transparency and radial through-hole mounting. The component operates at a forward voltage of 3.4V and a test current of 20mA, emitting light at a primary wavelength of 470nm. It delivers a luminous intensity of 1310 mcd with a viewing angle of 100° x 40°. The device is RoHS compliant and has a maximum height of 10.95mm.

Feature Summary

• High-intensity blue light emission optimized for visibility in video screen applications
• Oval dome lens design providing wide horizontal viewing angles
• Through-hole radial package construction for secure board mounting

Applications

• Large-format high-resolution video screens
• Digital advertising signage
• Stadium display ribbons

Procurement Notes

Verify the specific ordering suffix to ensure correct binning for luminous intensity and wavelength. Confirm that the required packaging quantity matches standard factory pack sizes. Check datasheet revisions for any chemical dipping or labeling updates. Ensure compatibility with existing through-hole assembly processes. Validate RoHS compliance status against current regulatory requirements.

Selection Notes

Select this component when high brightness is required for outdoor or large-scale display environments. The oval shape and wide beam angle facilitate uniform light distribution across viewing areas. Consider the 5mm form factor for space-constrained PCB layouts requiring robust mechanical retention. Evaluate thermal management needs based on continuous operating currents.

Part Context

This part belongs to the Screen Master series, which focuses on high-brightness LEDs for demanding visual applications. The C5SMF base indicates a 5mm oval package style within Cree's discrete LED portfolio. These components are engineered to replace older technologies in modern digital signage infrastructure.

Replacement Considerations

Direct substitutes include other C5SMF variants with matching electrical parameters. Verify pinout orientation and lens color consistency when cross-referencing similar models. Ensure replacement parts maintain the same mounting dimensions and thermal characteristics.
