CA3506M10RP-NH

Headers, Male Pins Overview

The CA3506M10RP-NH is a surface mount male pin header manufactured by Cvilux USA. It features a 1.27mm (0.050 inch) pitch with six positions arranged in a single row. The connector utilizes right-angle termination for PCB mounting and employs tin-plated brass contacts. The housing is constructed from glass-filled PA6T nylon, rated UL94 V-0 for flammability. Operating temperatures range from -40°C to 105°C.

Headers, Male Pins Feature Summary

• Surface mount design for automated assembly
• Right-angle termination configuration
• Tin-plated brass contact construction
• High-temperature resistant polymer housing

Headers, Male Pins Applications

• Consumer electronics interconnects
• Direct wire-to-board connections
• General electronic circuit board assemblies

Headers, Male Pins Procurement Notes

Verify the specific suffix 'NH' against the manufacturer's current datasheet to confirm environmental compliance status and material specifications. Ensure the selected variant matches the required surface mount orientation and pitch tolerance for the target PCB layout. Cross-reference the part number with official Cvilux documentation to confirm active status and lead time requirements before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mounted header with a 1.27mm pitch is required. The right-angle design facilitates compact vertical stacking or side-entry wiring configurations. Ensure the PCB footprint accommodates the specified contact length and isolation height. Verify that the operating temperature range meets the environmental demands of the end application.

Headers, Male Pins Part Context

This part belongs to the CA35 series of rectangular connectors from Cvilux USA. The series includes various configurations such as through-hole and different pin counts. The CA3506M10RP-NH specifically denotes a 6-position, right-angle, surface-mount variant within this family, designed for reliable signal transmission in space-constrained electronic devices.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 1.27mm pitch surface mount headers from manufacturers like Molex or Samtec, provided they match the 6-position count and right-angle form factor. Verify mechanical dimensions and electrical ratings before substitution.
