CA3506V1100-NH

Headers, Male Pins Overview

The CA3506V1100-NH is a male header connector from the Cvilux USA Micro-MaTch series. It features a 0.050 inch (1.27mm) pitch and six positions in a single row. Designed for vertical through-hole mounting, it utilizes brass contacts with tin plating and a glass-filled polyamide insulation material rated UL94 V-0. The component operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Vertical through-hole mounting style for direct board integration
• Micro-MaTch series design ensuring precise 0.050 inch spacing
• Tin-plated brass contacts for reliable electrical conductivity
• Glass-filled polyamide insulation providing thermal stability

Headers, Male Pins Applications

• Board-to-board interconnections requiring vertical orientation
• General electronic equipment internal wiring
• Consumer electronics assembly lines
• Industrial control panel signal routing

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Cvilux datasheet to confirm pin count and termination type. Ensure compatibility with mating female headers from the same series. Confirm that the vertical configuration matches the mechanical layout requirements of the target printed circuit board design before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a vertical orientation is required for space-constrained designs. The 0.050 inch pitch suits high-density applications. Verify that the operating temperature range meets environmental demands. Ensure the tin-plated contact finish aligns with soldering process requirements and mating connector specifications.

Headers, Male Pins Part Context

This part belongs to the Micro-MaTch family, characterized by compact dimensions and reliable performance. The CA3506V1100-NH variant specifically denotes a six-position vertical header. It complements other series components like the CA3506H1100-NH, which offers a right-angle alternative for different spatial constraints.

Headers, Male Pins Replacement Considerations

Direct substitutes include other six-position vertical headers with identical 0.050 inch pitch from compatible manufacturers. Ensure mating connectors share the same contact geometry and current rating. Cross-reference mechanical drawings for height and footprint compatibility before substitution.
