CA3508H1100-NH

Headers, Male Pins Overview

The CA3508H1100-NH is a Micro-MaTch series connector header manufactured by Cvilux USA. It features a 6-position configuration with a 0.050 inch (1.27mm) pitch. The component utilizes through-hole, right-angle termination for reliable PCB mounting. Constructed with male pins, it supports standard interconnect requirements in compact electronic assemblies.

Headers, Male Pins Feature Summary

• Micro-MaTch series design for compact electronics
• Right-angle through-hole mounting orientation
• Male pin contact type for header applications

Headers, Male Pins Applications

• Consumer electronics assembly
• General-purpose circuit board interconnection
• Compact device internal wiring

Headers, Male Pins Procurement Notes

Verify the specific part number against official Cvilux documentation to confirm pin count and pitch accuracy. Ensure compatibility with existing PCB footprint designs before procurement. Cross-reference manufacturer datasheets for mechanical dimensions and material specifications to guarantee proper integration into the target electronic system.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle header is required for space-constrained designs. The 1.27mm pitch offers a balance between density and ease of assembly. Consider the through-hole mounting method for robust mechanical stability compared to surface-mount alternatives in high-vibration environments.

Headers, Male Pins Part Context

This part belongs to the Micro-MaTch family from Cvilux USA, a brand established in 1990 specializing in connectors and FFC solutions. The product line targets consumer electronics and general interconnect needs, providing standardized components for various industrial and commercial applications.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical fit and electrical ratings before considering alternative manufacturers.
