CA3510V1100-NH

Headers, Male Pins Overview

The CA3510V1100-NH is a male header connector manufactured by Cvilux USA. It features a vertical through-hole mounting configuration with a pin spacing of 1.27mm (0.050 inches). The component consists of 10 positions arranged in a single row. This connector is designed for board-to-board or board-to-wire connections in electronic assemblies requiring reliable signal transmission.

Headers, Male Pins Feature Summary

• Vertical male pin orientation for standard PCB insertion
• Through-hole mounting technology for secure mechanical attachment
• Single row configuration with 10 contact positions

Headers, Male Pins Applications

• Consumer electronics internal interconnections
• General-purpose circuit board assembly
• Signal routing in compact electronic devices

Headers, Male Pins Procurement Notes

Verify the manufacturer part number CA3510V1100-NH against official Cvilux documentation to ensure authenticity. Confirm that the required specifications match the vertical DIP format and 1.27mm pitch. Check for any specific RoHS compliance markings if environmental regulations apply to your project. Ensure the supplier provides traceable origin data for quality assurance purposes.

Headers, Male Pins Selection Notes

Select this component when a vertical male header with 10 pins and 1.27mm spacing is required. Consider the through-hole mounting requirement and operating temperature range of -40°C to 105°C. Verify that the board guide feature, if present in related variants, meets alignment needs. Ensure the physical dimensions fit within the designated footprint on the printed circuit board.

Headers, Male Pins Part Context

This part belongs to the Cvilux USA series of connectors, which includes headers, FFC cables, and wire harnesses. The product line primarily targets consumer electronics applications. The CA3510V1100-NH represents a standard vertical male pin configuration within their broader portfolio of interconnect solutions.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult Cvilux technical support for direct equivalents or cross-reference options based on specific electrical and mechanical requirements.
