CA4-10.000-18-3050-R

Crystals Overview

The CA4-10.000-18-3050-R is a surface-mount quartz crystal resonator manufactured by Aker Technology Corp. It operates at a standard frequency of 10 MHz with a frequency tolerance of ±30 ppm and stability of ±50 ppm. The component utilizes an HC-49-US package configuration with four pins, measuring 13 mm in length, 4.7 mm in width, and 5.2 mm in height. It features a load capacitance of 18 pF and a series resistance of 50 Ω. The device supports an operating temperature range from -40°C to 85°C and complies with RoHS standards.

Crystals Feature Summary

• Surface-mount design utilizing the HC-49-US package format for compact integration
• Quartz resonator providing stable oscillation at 10 MHz with specified frequency tolerance
• Operational capability across extended industrial temperature ranges

Crystals Applications

• General-purpose clock signal generation in electronic circuits
• Timing reference sources for microcontroller systems
• Oscillator circuits requiring precise frequency stability

Crystals Procurement Notes

Verify the specific suffix designation against official manufacturer documentation to ensure accurate part identification. Confirm that the required frequency tolerance and load capacitance align with the target circuit design specifications. Check current availability status as supply conditions may vary. Ensure compliance with relevant environmental regulations for the intended application environment.

Crystals Selection Notes

Select this component when a surface-mount quartz crystal is required for 10 MHz applications. Consider the HC-49-US form factor for board space constraints. Evaluate the ±30 ppm tolerance against system timing requirements. Verify compatibility with the oscillator circuit's load capacitance needs. Assess thermal performance within the specified operating temperature range.

Crystals Part Context

This part belongs to the CA4 series of surface-mount crystals from Aker Technology Corp. The series offers various frequency options within standardized package dimensions. The CA4 designation indicates a specific pin configuration and mechanical footprint suitable for automated assembly processes. This model represents a standard commercial-grade option within the broader product line.

Crystals Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
