CDR2014

Overview

The CDR2014 is a ceramic band pass filter manufactured by RFMi, designed for Sub-6G and 5G wireless applications. It operates with a center frequency of 4.7GHz and features a bandwidth of 600 MHz. The component maintains a standard impedance of 50 Ohms. This device provides signal isolation and frequency selection capabilities critical for modern digital and wireless communication systems.

Feature Summary

• Designed for Sub-6G and 5G wireless applications
• Provides signal isolation and frequency selection
• Utilizes ceramic technology for robust performance

Applications

• Sub-6G wireless communications
• 5G network infrastructure
• Digital wireless systems requiring frequency selection

Procurement Notes

Verify the specific datasheet version to confirm exact electrical tolerances and mechanical dimensions before integration. Ensure compatibility with existing PCB layouts and thermal management requirements. Confirm RoHS compliance status if required by your manufacturing standards. Cross-reference part numbers with official RFMi documentation to avoid counterfeit components.

Selection Notes

Select this component when operating within the 4.7GHz center frequency range. Consider the 600 MHz bandwidth relative to your signal requirements. Evaluate the 50 Ohm impedance match against your system's transmission lines. Assess the ceramic construction benefits for your specific environmental conditions.

Part Context

RFMi, an Akoustis brand, specializes in RF components using SAW, Xtal, and Ceramic technologies. The CDR2014 belongs to their ceramic filter portfolio, targeting high-frequency wireless applications. This product line supports digital and wireless communication needs through precise frequency control and filtering solutions.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
