CDRH4D15/SNP-2R2NC

$0.72

Description：FIXED IND 2.2UH 2.6A 60 MOHM SMD
Series：CDRH4D15/S
Mfr：Sumida America Components Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:ee3c291f6dc3 Category: Fixed Inductors Brand: Sumida America Components Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CDRH4D15/SNP-2R2NC is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Sumida America Components Inc.. Its product description is FIXED IND 2.2UH 2.6A 60 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for CDRH4D15/SNP-2R2NC

Description：FIXED IND 2.2UH 2.6A 60 MOHM SMD
Series：CDRH4D15/S
Mfr：Sumida America Components Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：Ferrite
Inductance：2.2 µH
Tolerance：±30%
Current Rating (Amps)：2.6 A
Current - Saturation (Isat)：2A
Shielding：Shielded
DC Resistance (DCR)：60mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 105°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.173" L x 0.173" W (4.40mm x 4.40mm)
Height - Seated (Max)：0.067" (1.70mm)
Features：-

Fixed Inductors datasheet and documents for CDRH4D15/SNP-2R2NC

CDRH4D15/SNP-2R2NC

Fixed Inductors Overview

The CDRH4D15/SNP-2R2NC is a surface-mount power inductor from Sumida, designed for compact electronic applications. It features a ferrite core and shielded construction to minimize electromagnetic interference. The component provides an inductance of 2.2 µH with a tolerance of ±30%. It supports a maximum DC current of 2.6 A and exhibits a maximum DC resistance of 60 mΩ. The physical dimensions are 4.5 mm in length, 4.5 mm in width, and 1.5 mm in height.

Fixed Inductors Feature Summary

Shielded wirewound design reduces magnetic flux leakage
Compact low-profile form factor suitable for space-constrained PCBs
Ferrite core material ensures stable performance across operating temperatures

Fixed Inductors Applications

DC-DC converter output filtering
Power supply input stages
General-purpose signal processing circuits

Fixed Inductors Procurement Notes

Verify the specific suffix designation against the manufacturer's official documentation to confirm exact electrical tolerances and packaging configurations. Ensure that the selected variant matches the required thermal and current ratings for the target application environment before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when a low-profile, shielded inductor is required for high-current applications. The 2.6 A rating and low DCR make it suitable for efficient power conversion stages where size constraints limit the use of larger unshielded alternatives.

Fixed Inductors Part Context

This part belongs to the CDRH4D15 series of surface-mount power inductors manufactured by Sumida America Components Inc. The series is characterized by its small footprint and robust shielding capabilities, catering to modern electronics that demand high reliability in minimal spaces.
