CF12JB6M80

Overview

The CF12JB6M80 is a carbon film axial through-hole resistor manufactured by Stackpole Electronics Inc. It features a resistance value of 6.8 MOhms with a tolerance of ±5%. The component has a power rating of 0.5W (1/2W) and operates within a temperature range of -55°C to +155°C. Its physical dimensions are 0.106 inches in diameter by 0.335 inches in length (2.70mm x 8.50mm). The device carries a flame-retardant coating for safety compliance and meets RoHS3 standards.

Feature Summary

• Flame-retardant safety coating
• Carbon film composition
• Wide operating temperature range

Applications

• General purpose electronic circuits
• Industrial control systems
• Consumer electronics assemblies

Procurement Notes

Verify the specific suffix against official manufacturer documentation to confirm exact tolerance, temperature coefficient, and packaging configuration. Ensure compatibility with existing PCB footprints and thermal management requirements before finalizing procurement decisions.

Selection Notes

Select this component when high resistance values are required in a standard half-watt axial package. Consider the wide temperature range and flame-retardant properties for applications demanding enhanced safety and environmental stability compared to standard general-purpose resistors.

Part Context

This part belongs to the CF series of carbon film resistors from Stackpole Electronics. The series offers various resistance values and power ratings, providing a reliable solution for general electronic applications requiring stable performance and cost-effectiveness.

Replacement Considerations

Cross-reference with other manufacturers' 6.8 MOhm 1/2W axial resistors ensuring identical tolerance and temperature coefficient specifications match the original design requirements.
