CF14JB1M80

Overview

The CF14JB1M80 is a fixed axial leaded carbon film resistor manufactured by Stackpole Electronics Inc. It features a resistance value of 1.8 MOhms with a tolerance of ±5%. The component has a power rating of 0.25W (1/4W) and operates within a temperature range of -55°C to +155°C. Its physical dimensions are 0.091 inches in diameter by 0.236 inches in length (2.30mm x 6.00mm). The part complies with RoHS3 standards and carries an ECCN code of EAR99.

Feature Summary

• Constructed using carbon film technology for general-purpose applications
• Features flame retardant coatings as a standard safety characteristic
• Designed for through-hole mounting with axial leads

Applications

• General purpose commercial electronics
• Industrial circuit protection
• Consumer appliance control boards

Procurement Notes

Verify the specific manufacturer part number against official Stackpole Electronics documentation to ensure accuracy, as distributor listings may contain variations or errors. Confirm that the required packaging format matches your assembly needs, as availability varies between bulk, tape, and reel options. Check current compliance status regarding RoHS3 and REACH regulations before finalizing procurement decisions.

Selection Notes

Select this component when a standard 1.8 MOhm resistance value is required for general-purpose circuits. Ensure the PCB layout accommodates the axial lead spacing and overall body dimensions. Consider the ±5% tolerance and temperature coefficient characteristics to verify suitability for the intended operating environment and precision requirements.

Part Context

This resistor belongs to the CF series of carbon film components from Stackpole Electronics. The series is characterized by its flameproof construction and suitability for automated insertion processes. It serves as a fundamental passive component for current limiting and voltage division in various electronic assemblies.

Replacement Considerations

Direct substitutes include other 1.8 MOhm, 1/4W, ±5% axial carbon film resistors from manufacturers such as Yageo or Vishay, provided they meet the same dimensional and electrical specifications.
