CF14JB2R00

Overview

The CF14JB2R00 is an axial leaded carbon film resistor manufactured by SEI Stackpole. It features a resistance value of 2 Ohms with a tolerance of ±5%. The component has a power rating of 250 mW (1/4 W) and operates within a temperature range of -55°C to +155°C. It includes a voltage rating of 350 V and exhibits a temperature coefficient of 0 PPM/°C to -400 PPM/°C. Physical dimensions include a diameter of 2.3 mm and a length of 6 mm, with leads measuring 0.55 mm in diameter.

Feature Summary

• Utilizes carbon film technology for general-purpose resistance applications.
• Designed for through-hole PCB mounting with axial termination style.

Applications

• General purpose electronic circuits
• PCB mounted assemblies

Procurement Notes

Verify the specific packaging configuration required for production, as this part number is associated with bulk packaging. Confirm that the minimum order quantity aligns with supplier distribution requirements. Ensure compliance with RoHS directives and check for any specific handling instructions related to axial components during assembly processes.

Selection Notes

Select this component when a low-value, high-tolerance resistor is needed for standard current limiting or biasing tasks. The wide operating temperature range supports use in demanding environments. Consider the physical size constraints of the target PCB layout to ensure adequate clearance for the axial leads and body dimensions.

Part Context

This resistor belongs to the CF series of carbon film components from SEI Stackpole. These parts are designed for cost-effective solutions in consumer electronics and industrial equipment. The axial form factor allows for easy insertion into printed circuit boards, providing reliable electrical connections for various analog and digital signal processing applications.

Replacement Considerations

CF14JT2R00
