CF14JB47R0

Overview

The CF14JB47R0 is a through-hole axial resistor manufactured by Stackpole Electronics Inc. It features a carbon film composition with a resistance value of 47 ohms and a tolerance of ±5%. The component has a power rating of 0.25W (1/4W) and operates within a temperature range of -55°C to +155°C. Its physical dimensions are approximately 2.3mm in diameter and 6.0mm in length. The device complies with RoHS3 standards and carries an ECCN classification of EAR99.

Feature Summary

• Utilizes carbon film technology for stable resistive performance
• Features flame-retardant coating for enhanced safety
• Designed for general-purpose PCB mounting applications

Applications

• General purpose electronic circuits
• Consumer electronics assemblies
• Industrial control equipment

Procurement Notes

Verify the specific manufacturer part number against official Stackpole documentation to ensure accuracy. Confirm that the required tolerance, power rating, and termination style match the design specifications. Check current availability status as lead times may vary. Ensure compliance with project-specific environmental regulations such as RoHS3 before finalizing procurement decisions.

Selection Notes

Select this component when a standard 47-ohm resistance with 5% tolerance is required for low-cost general-purpose applications. Consider the 1/4W power rating and axial package constraints during layout planning. Evaluate the operating temperature range to ensure suitability for the intended environmental conditions. Compare against alternative series if tighter tolerances or different materials are needed.

Part Context

This resistor belongs to the CF series of carbon film components from Stackpole Electronics. These parts are widely used in cost-sensitive designs where precise stability is not critical. The axial form factor allows for easy insertion into printed circuit boards. The series offers a broad range of resistance values and power ratings for diverse electronic needs.

Replacement Considerations

CF14GB47R0 is listed as a parameter-equivalent substitute.
