CF18JB2M00

Overview

The CF18JB2M00 is a fixed carbon film resistor manufactured by Stackpole Electronics Inc. It features an axial through-hole mounting style with a resistance value of 2 MOhms and a tolerance of ±5%. The component has a power rating of 1/8 W (125 mW) and operates within a temperature range of -55°C to +155°C. It utilizes a tubular package with dimensions of 1.70mm diameter by 3.30mm length. The device carries RoHS compliance and is classified under the CF series.

Feature Summary

• Constructed using carbon film technology for stable resistive performance
• Features flame retardant coatings as standard for safety
• Designed for general purpose commercial and industrial applications

Applications

• Commercial electronic equipment
• Industrial control circuits
• General purpose PCB mounting

Procurement Notes

Verify the specific suffix designation against official datasheets to confirm packaging type, as variations exist within the CF series. Confirm RoHS status and lead times directly with the manufacturer or authorized distributors prior to ordering. Ensure the axial lead configuration matches the target PCB layout requirements.

Selection Notes

Select this component when a 2 MOhm resistance with 5% tolerance is required in a compact axial form factor. Consider the 1/8 W power rating and wide operating temperature range for suitability in space-constrained designs. Verify compatibility with automated insertion processes if Panasert availability is needed for selected sizes.

Part Context

This part belongs to the CF series of carbon film resistors from Stackpole Electronics. The series offers various resistance values and power ratings, standardized for general-purpose use. The CF18JB2M00 specifically denotes the 1/8 W axial variant within this family, sharing common construction characteristics with other members like the CF18JA and CF18JT series.

Replacement Considerations

CF18JT2M00 is listed as a parameter equivalent substitute.
