CF18JB2M70

Overview

The CF18JB2M70 is a carbon film through-hole resistor manufactured by SEI Stackpole. It features a resistance value of 2.7 MOhms with a tolerance of ±5%. The component has a power rating of 0.125W (1/8W) and utilizes an axial package style for PCB mounting. It operates within a temperature range of -55°C to +155°C and includes standard flame retardant coatings.

Feature Summary

• Constructed using carbon film technology for general-purpose commercial and industrial applications
• Equipped with standard flame retardant coatings for enhanced safety
• Designed for axial PCB mounting in electronic circuits

Applications

• General purpose commercial electronics
• Industrial control circuitry
• Signal conditioning networks

Procurement Notes

Verify the specific packaging configuration, such as Ammo Pack or Reel, when placing orders, as availability may vary by distributor. Confirm RoHS compliance status directly with the manufacturer or authorized suppliers prior to procurement to ensure adherence to environmental regulations required for your specific manufacturing processes.

Selection Notes

Select this component for designs requiring stable performance in general-purpose analog or digital circuits. Ensure the operating voltage does not exceed the maximum limits defined in the official datasheet. Verify that the axial lead spacing matches the printed circuit board layout requirements before finalizing the bill of materials.

Part Context

This part belongs to the CF_CFM series of carbon film resistors from SEI Stackpole. The series is characterized by its reliability and cost-effectiveness for high-volume production environments. The CF18JB2M70 specifically denotes the 2.7 MOhm variant within this standardized product line.

Replacement Considerations

Direct substitutes include other 2.7 MOhm, 1/8W, ±5% tolerance carbon film resistors from different manufacturers, provided they meet the same axial package dimensions and thermal specifications.
