CF18JB82R0

Overview

The CF18JB82R0 is a fixed carbon film resistor manufactured by Stackpole Electronics Inc. It features an axial through-hole package with a resistance value of 82 ohms and a tolerance of ±5%. The component has a power rating of 0.125W (1/8W) and operates within a temperature range of -55°C to +155°C. Its physical dimensions are 1.70mm in diameter and 3.30mm in length. The device complies with RoHS3 standards and carries an EAR99 classification.

Feature Summary

• Constructed using carbon film technology for general-purpose resistive applications
• Features a flame-retardant coating for enhanced safety compliance
• Designed for axial leaded through-hole mounting on printed circuit boards

Applications

• Commercial electronic equipment circuits
• Industrial control system components
• General-purpose PCB mounting applications

Procurement Notes

Verify the specific suffix against official Stackpole documentation to confirm exact packaging configuration, as standard bulk or tape-and-reel options may vary. Confirm that the requested quantity aligns with manufacturer minimum order requirements and standard factory lead times before finalizing procurement plans.

Selection Notes

Select this component when a standard 82-ohm resistance with 5% tolerance is required for low-power axial applications. Ensure the operating environment remains within the specified -55°C to +155°C range. Verify that the 1/8W power rating is sufficient for the intended circuit load conditions.

Part Context

This part belongs to the CF series of carbon film resistors from Stackpole Electronics. The series is characterized by its flame-retardant construction and suitability for commercial and industrial environments. The CF18JB82R0 represents a specific resistance value within this standardized axial leaded product line.

Replacement Considerations

CF18JA82R0 is documented as a parameter-equivalent substitute within the same manufacturer's portfolio.
