CF4024M00018T1521002

Crystals Overview

The CF4024M00018T1521002 is a quartz crystal resonator manufactured by Hefei Jingweite Electronics Co., Ltd. It operates at a fundamental frequency of 24 MHz with a frequency tolerance of ±10 ppm. The component features a load capacitance of 18 pF and an equivalent series resistance (ESR) of 30 Ohms. It is housed in a 4-SMD, No Lead package, specifically identified as a 3225 surface-mount device. The unit is RoHS compliant and designed for precision timing applications requiring stable oscillation.

Crystals Feature Summary

• Provides precise 24 MHz frequency generation with ±10 ppm stability
• Utilizes a compact 3225 SMD footprint for space-constrained designs
• Features low ESR of 30 Ohms for efficient circuit integration

Crystals Applications

• Microcontroller clock sources
• Communication module timing references
• Digital signal processing circuits

Crystals Procurement Notes

Verify the manufacturer part number CF4024M00018T1521002 against official Hefei Jingweite Electronics documentation to confirm specifications. Ensure compatibility with 18 pF load capacitance requirements. Check for RoHS compliance status if required by project regulations. Confirm package dimensions match the 3225 SMD form factor before procurement.

Crystals Selection Notes

Select this component when a 24 MHz reference with ±10 ppm accuracy is required. The 30 Ohm ESR suits standard oscillator circuits. The 18 pF load capacitance must match the host circuit design. The 3225 SMD package is suitable for automated surface-mount assembly processes.

Crystals Part Context

Hefei Jingweite Electronics Co., Ltd. specializes in the research, development, and production of high-quality quartz crystals. This company is recognized as a national high-tech enterprise focusing on reliable resonator solutions. The CF4024M00018T1521002 represents their standard surface-mount crystal offering within the broader portfolio of electronic components.

Crystals Replacement Considerations

Consult official cross-reference lists from Hefei Jingweite Electronics for verified substitutes. Ensure any replacement matches the 24 MHz frequency, 18 pF load capacitance, and 3225 package dimensions. Verify that alternative parts maintain the ±10 ppm tolerance and 30 Ohm ESR specifications.
