CFMH6-5.000-F06IL35A

Overview

The CFMH6-5.000-F06IL35A is a quartz crystal resonator manufactured by Suzhou Hangjing Elec & Tech Co., Ltd. This component operates at a fundamental frequency of 5.000 MHz and utilizes the HC-49/U package style, which is a standard through-hole housing for general-purpose frequency control applications. The part number designation indicates specific load capacitance and frequency tolerance parameters defined by the manufacturer's internal coding system. As a passive frequency-determining element, it requires external oscillator circuitry to generate clock signals for digital systems.

Feature Summary

• Provides stable frequency reference for digital logic circuits
• Utilizes standard through-hole mounting configuration
• Engineered for consistent performance in consumer electronics

Applications

• Smartphone timing circuits
• Tablet device clock generation
• In-vehicle electronic systems

Procurement Notes

Verify the exact electrical specifications, including load capacitance and equivalent series resistance, against the official datasheet XC75M4-18.432-F18NJDTK.pdf or current product documentation. Confirm that the HC-49/U package dimensions match your PCB footprint requirements before finalizing procurement decisions.

Selection Notes

Select this component when a 5 MHz fundamental mode crystal is required for cost-sensitive consumer applications. Ensure the target circuit design supports the specific load capacitance implied by the suffix code. Validate compatibility with the operating temperature range specified in the manufacturer's technical data sheets.

Part Context

Suzhou Hangjing Elec & Tech Co., Ltd. specializes in quartz frequency controlling units, including crystals, oscillators, and filters. Founded in 2014, the company focuses on R&D and production of these components for global electronics markets, serving sectors such as mobile communications and automotive systems.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided source material. Cross-referencing with other manufacturers requires independent verification of pinout, frequency stability, and mechanical dimensions.
