CG02611-32M

Overview

The CG02611-32M is a surface-mount crystal oscillator manufactured by NDK. It operates at a fundamental frequency of 32 MHz with a load capacitance of 10 pF. The unit provides a frequency tolerance of ±20 ppm. The component utilizes a 4-SMD, no-lead package design suitable for automated assembly processes.

Feature Summary

• Surface-mount configuration for direct PCB integration
• Fundamental mode oscillation at 32 MHz
• Standard 10 pF load capacitance specification

Applications

• General-purpose clock signal generation in electronic circuits
• Microcontroller system timing references
• Communication interface synchronization modules

Procurement Notes

Verify the specific ordering suffix to confirm packaging format. Distributors list variants such as TR for tape and reel or CT for cut tape. Ensure the selected variant matches the required manufacturing equipment capabilities. Confirm the manufacturer part number aligns exactly with the requested specifications before finalizing the purchase order.

Selection Notes

Select this component when a 32 MHz reference is required for SMD assembly lines. The 10 pF load capacitance must match the circuit design requirements. Evaluate the ±20 ppm tolerance against the system's timing accuracy needs. Consider the 4-SMD footprint dimensions for board layout constraints.

Part Context

This component belongs to the NDK crystal oscillator family designed for consumer and industrial electronics. It serves as a passive frequency control element providing stable oscillation. The product line emphasizes reliability and standardization for mass production environments across various hardware platforms.

Replacement Considerations

Consult official substitution guides for compatible alternatives. Verify that any replacement maintains identical frequency, load capacitance, and package dimensions. Cross-reference electrical parameters to ensure functional equivalence within the target application circuit.
