CH88122C100-B

Headers, Male Pins Overview

The CH88122C100-B is a dual-row rectangular connector header manufactured by Cvilux USA. It features 12 positions with a 0.100-inch (2.54mm) pitch. The component utilizes through-hole mounting for secure board attachment. It is designed as a male pin header intended for board-to-board or cable connections. The connector supports a current rating of 3A, ensuring reliable electrical performance in standard electronic assemblies.

Headers, Male Pins Feature Summary

• Dual-row configuration for increased pin density
• Through-hole mounting style for robust mechanical stability
• Male pin contact type for mating with female sockets

Headers, Male Pins Applications

• Consumer electronics internal interconnections
• General-purpose circuit board assembly
• Industrial control panel wiring

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official Cvilux USA documentation to ensure authenticity. Confirm that the received components match the specified 12-position dual-row format and through-hole package. Check for compliance with relevant environmental standards such as RoHS3 before integration into final products.

Headers, Male Pins Selection Notes

Select this component when a 12-position dual-row male header is required for through-hole PCB mounting. Ensure the design accommodates the 2.54mm pitch and 3A current rating. Consider the physical dimensions and row spacing to verify compatibility with mating connectors and available board space in the target application.

Headers, Male Pins Part Context

This part belongs to the Cvilux USA rectangular connector family, specifically designed for headers and wire housings. It serves as a standard interconnection solution within their portfolio of electronic components. The product line focuses on providing reliable connectivity options for various consumer and industrial electronic devices.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain identical 12-position count, dual-row layout, 2.54mm pitch, and through-hole mounting. Verify that alternative parts support the same 3A current rating and male pin interface to ensure functional interchangeability without redesigning the PCB footprint.
