CHF9838CBF101R

Description：RES CHAS MNT 100 OHM 5% 250W
Series：CHF - RF Power
Mfr：Bourns Inc.
Package：Tray

SKU:f729bb9ecc0b Category: RF Misc ICs and Modules Brand: Bourns Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RES CHAS MNT 100 OHM 5% 250W
Series：CHF - RF Power
Mfr：Bourns Inc.
Package：Tray
Function：Termination
Frequency：0Hz ~ 3GHz
RF Type：General Purpose
Secondary Attributes：-
Mounting Type：Flange Mount
Package / Case：Flat Box, Terminator
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

CHF9838CBF101R

Overview

The CHF9838CBF101R is a stripline resistor manufactured by Bourns Inc., designed for high-frequency and RF applications. It features a chassis mount configuration with a resistance value of 100 ohms and a power rating of 250 watts. The component exhibits a tolerance of 5% and operates within a frequency range of 0 Hz to 3 GHz. Classified as an RF IC termination, it utilizes a flat box terminator package style. This part is currently listed as obsolete in the manufacturer's lifecycle status.

Feature Summary

Stripline construction optimized for high-frequency signal integrity
High power handling capability suitable for demanding RF environments
Chassis mount design for robust mechanical installation

Applications

RF IC termination
High-frequency circuit impedance matching
Signal processing systems requiring stripline resistors

Procurement Notes

Verify component obsolescence status before integration into new designs. Confirm datasheet specifications for frequency response and power ratings against current project requirements. Ensure compatibility with existing chassis mounting infrastructure. Review alternative sourcing options due to discontinued lifecycle status. Validate electrical parameters through independent testing if critical for system performance.

Selection Notes

Select this component only when specific 100-ohm, 250-watt stripline characteristics are required for RF termination. Consider the 0 Hz to 3 GHz operational bandwidth during circuit design. Evaluate chassis mounting constraints and thermal management needs. Assess availability challenges associated with obsolete parts. Compare against newer series if long-term supply stability is a priority.

Part Context

This resistor belongs to Bourns' High Frequency/RF Resistors category, specifically engineered for stripline applications. It serves as a general-purpose RF IC termination solution. The product line emphasizes high-power handling in compact terminator packages. Bourns designs these components to maintain signal integrity in high-frequency environments while dissipating significant energy loads effectively.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Due to the obsolete lifecycle status, direct replacements may require redesigning the PCB layout or adjusting power handling specifications. Consult manufacturer archives for legacy cross-reference data.
