CI0102M1HR0-NH

Headers, Male Pins Overview

The CI0102M1HR0-NH is a rectangular connector header manufactured by Cvilux USA, designed for board-to-cable or wire applications. It features a single row of two positions with a pitch of 0.079 inches (2.00mm). The component utilizes male pin contacts made of brass with tin plating, secured via solder termination in a surface mount right-angle configuration. Constructed from halogen-free PA6T insulation rated UL94 V-0, it supports a working temperature range of -25°C to 105°C and carries RoHS3 compliance.

Headers, Male Pins Feature Summary

• Surface mount right-angle installation for compact PCB integration
• Halogen-free PA6T insulation material ensuring environmental compliance
• Tin-plated brass contacts providing reliable electrical conductivity
• UL94 V-0 flammability rating for enhanced safety standards

Headers, Male Pins Applications

• Board-to-cable interconnections
• Wire-to-board connections
• General electronic circuit assembly
• Consumer electronics manufacturing

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to ensure correct packaging and terminal type compatibility. Confirm that the associated housing and contact components match the 2.00mm pitch specification. Check RoHS3 status requirements against project regulations. Ensure soldering parameters align with surface mount right-angle processing standards to maintain mechanical integrity.

Headers, Male Pins Selection Notes

Select this model when a low-profile, right-angle header is required for tight spatial constraints. The 2.00mm pitch suits applications needing moderate spacing between pins. Consider the 1A current rating and 250VAC voltage limit for circuit design. Verify that the natural color and single-row layout fit the assembly aesthetic and routing needs.

Headers, Male Pins Part Context

This component belongs to the CI01 series of rectangular connectors from Cvilux USA. The series offers various position counts and mounting styles, including through-hole and surface mount options. The CI01 series is characterized by its robust construction and compliance with international environmental standards, serving as a versatile solution for diverse electronic interconnection requirements.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 2-position, 2.00mm pitch headers from Cvilux such as CI0102M1VR0-NH for straight surface mount or CI0102P1VK0-NH for through-hole variants. Ensure any replacement maintains the same current, voltage, and temperature ratings to guarantee functional equivalence.
