CI0104P2VK0-NH

$0.09

Description：CONN HEADER TH 4POS 2.0MM
Series：CI01
Mfr：Cvilux USA
Package：Bulk

SKU:ed12a362a52c Category: Headers, Male Pins Brand: Cvilux USA

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

CI0104P2VK0-NH is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Cvilux USA. Its product description is CONN HEADER TH 4POS 2.0MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for CI0104P2VK0-NH

Description：CONN HEADER TH 4POS 2.0MM
Series：CI01
Mfr：Cvilux USA
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：4
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Kinked Pin, Solder
Fastening Type：Detent Lock
Contact Length - Mating：-
Contact Length - Post：0.134" (3.40mm)
Overall Contact Length：-
Insulation Height：0.240" (6.10mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：Gold
Contact Material：Brass
Insulation Material：Polyamide (PA66), Nylon 6/6
Features：-
Operating Temperature：-25°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Natural
Current Rating (Amps)：2A
Voltage Rating：250VAC/DC

Headers, Male Pins datasheet and documents for CI0104P2VK0-NH

CI0104P2VK0-NH

Headers, Male Pins Overview

The CI0104P2VK0-NH is a rectangular header connector manufactured by Cvilux USA, designed for through-hole mounting. It features a single row of four male pins with a 2.00mm (0.079 inch) pitch. The connector utilizes gold-plated contacts housed in a black insulator made of polyamide (PA6T). Rated for 2A current and 250VAC/DC voltage, it operates within a temperature range of -25°C to 105°C. The component meets UL94 V-0 flammability standards and complies with RoHS3 regulations.

Headers, Male Pins Feature Summary

Through-hole mounting configuration for secure PCB attachment
Gold-plated contact surfaces for reliable signal transmission
Black polyamide insulation housing with UL94 V-0 rating

Headers, Male Pins Applications

General electronic circuit interconnections
Consumer electronics assembly
Industrial control board connections

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Cvilux documentation to ensure correct pin count and pitch specifications. Confirm that the required RoHS3 compliance aligns with project environmental standards. Cross-reference the datasheet for precise mating dimensions to guarantee compatibility with intended cable or board assemblies before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row header with a 2.00mm pitch is required for through-hole applications. Ensure the 2A current rating and 250VAC/DC voltage limits meet the system's electrical requirements. Consider the operating temperature range and UL94 V-0 material classification for appropriate thermal and fire safety performance in the target environment.

Headers, Male Pins Part Context

This part belongs to the CI01 series of rectangular connectors from Cvilux USA, which are widely used in various electronic industries including consumer, computer, and communication sectors. The series offers multiple configurations to support diverse interconnection needs across global markets.
