CI0106M1VR0-NH

Headers, Male Pins Overview

The CI0106M1VR0-NH is a surface mount header connector manufactured by Cvilux USA, featuring six positions in a single row with a 2.00mm pitch. It utilizes male pin contacts made of brass with tin plating, offering a mating contact length of 3.61mm and a column plating thickness of 3.05µm. The housing is constructed from halogen-free PA6T nylon with a natural color and UL94 V-0 flammability rating. Rated for 2A current and 250VAC/DC voltage, it operates within a temperature range of -25°C to 105°C. The component includes a four-wall shielded shroud and employs a pin lock fastening type for secure board-to-cable or wire connections.

Headers, Male Pins Feature Summary

• Surface mount installation with solder termination for reliable PCB attachment
• Four-wall shielded shroud design providing environmental protection
• Halogen-free PA6T insulation material ensuring compliance with environmental standards
• Pin lock fastening mechanism to secure mating connections

Headers, Male Pins Applications

• Automotive hybrid, electric, and powertrain systems
• General electronic equipment requiring board-to-wire interconnects
• Industrial control modules utilizing surface mount technology

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix VR0 against official Cvilux documentation to confirm packaging and terminal configuration details. Ensure compatibility with mating connectors regarding pitch and shroud dimensions. Confirm RoHS3 compliance status through manufacturer certificates prior to integration into regulated assemblies.

Headers, Male Pins Selection Notes

Select this component when a 2.00mm pitch surface mount header is required for high-temperature environments up to 105°C. Consider the 2A current rating and 250VAC/DC voltage limits for circuit design. The four-wall shroud and pin lock features are suitable for applications demanding enhanced mechanical stability and shielding.

Headers, Male Pins Part Context

This part belongs to the CI01 series of rectangular connectors from Cvilux USA. It shares common design characteristics with other variants in the series, such as similar insulation materials and mounting styles, but differs in position count and pitch specifications. The CI01 series is designed for general-purpose interconnect applications requiring robust surface mount performance.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.00mm pitch, 6-position configuration, and surface mount termination. Verify that alternative headers provide equivalent current ratings (2A) and voltage ratings (250VAC/DC). Ensure compatible shroud types and pin lock mechanisms if mechanical retention is critical.
