CI1104M1HR0-NH

Headers, Male Pins Overview

The CI1104M1HR0-NH is a single-row surface mount header manufactured by Cvilux USA. It features four positions with a 1.00mm (0.039 inch) mating pitch. The connector utilizes phosphor bronze contacts with tin plating and is housed in halogen-free, glass-reinforced PA6T insulation rated UL94 V-0. Designed for right-angle mounting, it supports a maximum current of 1A AC/DC at 50VAC. The component operates within a temperature range of -25°C to 85°C and includes pin lock retention features.

Headers, Male Pins Feature Summary

• Right-angle surface mount design for space-constrained PCB layouts
• Halogen-free glass-reinforced PA6T insulation for environmental compliance
• Tin-plated phosphor bronze contacts ensure reliable conductivity
• Pin lock retention mechanism secures mating connections

Headers, Male Pins Applications

• Consumer electronics internal interconnections
• Industrial control board wiring
• Communication equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific suffix NH indicates halogen-free compliance when sourcing. Confirm right-angle orientation matches PCB assembly requirements. Ensure mating partners utilize compatible 1.00mm pitch connectors. Check RoHS3 documentation for regulatory adherence prior to integration into final products.

Headers, Male Pins Selection Notes

Select this model for applications requiring compact right-angle headers with strict halogen-free standards. Compare against vertical variants if panel penetration is needed. Validate thermal performance against the 85°C upper limit. Consider the 1A current rating for circuit load calculations before implementation.

Headers, Male Pins Part Context

This component belongs to the CI11 series of rectangular connectors from Cvilux USA. The series offers various pin counts and orientations. The CI1104M1HR0-NH specifically addresses needs for low-profile, high-density connections in modern electronic assemblies where standard through-hole headers are unsuitable.

Headers, Male Pins Replacement Considerations

Direct substitutes include other manufacturers' 4-position 1.00mm pitch right-angle SMT headers. Verify mechanical dimensions and contact material compatibility. Ensure equivalent electrical ratings and insulation properties match the original specification.
