CI1105M1VR0-NH

Headers, Male Pins Overview

The CI1105M1VR0-NH is a surface-mount wire-to-board header manufactured by Cvilux USA. It features five positions with a 1.00mm pitch and utilizes pin lock fastening. The connector employs tin-plated phosphor bronze contacts housed in halogen-free PA6T insulation rated UL94 V-0. Designed for single-row board-to-cable applications, it supports a maximum current of 1A at 50VAC. Operating temperatures range from -25°C to 85°C, ensuring reliable performance in standard electronic assemblies.

Headers, Male Pins Feature Summary

• Surface-mount design with pin lock retention
• Halogen-free PA6T insulation material
• Tin-plated phosphor bronze contacts
• Single-row configuration with four-wall shielding

Headers, Male Pins Applications

• Board-to-cable interconnections
• Wire-to-board connections
• General electronic assembly

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm exact specifications. Ensure compatibility with mating receptacles such as the CI1105S0000-NH housing. Confirm RoHS3 compliance status through the latest datasheet before integration into production workflows.

Headers, Male Pins Selection Notes

Select this component for applications requiring compact surface-mount headers with secure pin locking. The 1.00mm pitch suits dense circuit layouts. Verify that the 1A current rating and 50VAC voltage limit align with system requirements. Consider the -25°C to 85°C operating range for environmental suitability.

Headers, Male Pins Part Context

This part belongs to the CI11 series of rectangular connectors from Cvilux USA. The series offers various position counts and pitch options for wire-to-board applications. The CI1105 variant specifically provides a five-position configuration within this standardized family of surface-mount components.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source data.
