CI1506M1HR0-NH

Headers, Male Pins Overview

The CI1506M1HR0-NH is a single-row header connector manufactured by Cvilux USA, designed for surface-mount right-angle board-to-wire applications. It features six positions with a 1.50mm (0.059 inch) pitch. The housing is constructed from halogen-free PA6T reinforced with glass fiber, rated UL94 V-0, and colored black. Contacts are made of brass with tin plating on both the mating and tail sections. The component supports through-hole termination and utilizes a slide-lock fastening mechanism. It operates within a temperature range of -40°C to 105°C, carrying an MSL rating of Level 1.

Headers, Male Pins Feature Summary

• Surface-mount right-angle design facilitates compact PCB layouts
• Slide-lock fastening mechanism ensures secure mating engagement
• Halogen-free PA6T insulation provides high thermal stability

Headers, Male Pins Applications

• Automotive electronic systems
• Board-to-wire interconnections
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required six-position configuration and 1.50mm pitch before integration. Confirm compliance with RoHS3 standards and REACH regulations for the target market. Ensure the surface-mount right-angle orientation aligns with the mechanical constraints of the assembly. Validate that the tin-plated brass contacts meet the conductivity requirements of the circuit design.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle surface-mount header is required for six circuits. The 1.50mm pitch offers a balance between density and spacing compared to finer pitches. The black PA6T housing is suitable for environments requiring higher heat resistance than standard nylon. Consider the slide-lock feature if vibration resistance during operation is a priority for the application.

Headers, Male Pins Part Context

This connector belongs to the CP35 series, which focuses on power and signal interconnects with robust mechanical locking. Unlike the CI44 or CI11 series, the CP35 line typically utilizes brass contacts and slide-lock mechanisms rather than pin locks. This distinguishes it from smaller pitch headers in the manufacturer's portfolio.

Headers, Male Pins Replacement Considerations

No direct public substitute part numbers are confirmed in the provided documentation. Cross-reference with other 6-position, 1.50mm pitch SMD right-angle headers only if electrical and mechanical parameters match exactly.
