CI1506M1VR0-NH

Headers, Male Pins Overview

The CI1506M1VR0-NH is a surface mount header connector manufactured by Cvilux USA, belonging to the CI15 series. It features six positions with a 1.50mm (0.059 inch) mating pitch and utilizes pin-style contacts. The component employs a four-wall shroud design for alignment and incorporates pin-lock fastening mechanisms. Rated for 1A at 50VAC, it operates within a temperature range of -25°C to 85°C. Constructed from halogen-free plastic insulation and brass contacts with tin plating, it meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Six-position surface mount header configuration with 1.50mm pitch
• Four-wall shrouded design ensuring precise alignment during assembly
• Pin-lock fastening mechanism for secure mating connection
• Halogen-free polyamide insulation supporting lead-free manufacturing processes

Headers, Male Pins Applications

• Automotive electronic systems requiring reliable board-to-wire connections
• Consumer electronics utilizing surface mount technology for compact layouts
• Industrial control boards needing secure header interfaces

Headers, Male Pins Procurement Notes

Verify the specific part number CI1506M1VR0-NH against official manufacturer documentation to ensure compatibility with required pitch and current ratings. Confirm that the halogen-free material specifications meet project environmental compliance requirements. Cross-reference the pin-lock feature necessity with the mating housing design to guarantee mechanical retention integrity in the final assembly.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount header with a 1.50mm pitch is required for automotive or consumer applications. Ensure the design accommodates the four-wall shroud height and pin-lock mechanism. Verify that the 1A current rating and 50VAC voltage limit align with the circuit's electrical demands and thermal operating conditions.

Headers, Male Pins Part Context

This connector belongs to the CI15 series, designed for wire-to-board applications. It complements matching socket housings, such as the CI1506S0000, to form complete interconnect solutions. The series supports automated pick-and-place assembly due to its reel packaging and standardized dimensions, facilitating efficient production workflows.

Headers, Male Pins Replacement Considerations

Direct substitutes include other CI15 series headers with identical 1.50mm pitch and six-position count. Verify mechanical fit and electrical ratings before swapping. No alternative part numbers are explicitly confirmed as direct replacements in the provided data.
