CI2206P1VK0-NH

Headers, Male Pins Overview

The CI2206P1VK0-NH is a 6-position wire-to-board connector header from the CI22 series by Cvilux USA. It features a 2.50mm (0.098 inch) pin spacing and utilizes through-hole termination for PCB mounting. The connector employs IDC termination at the cable end, designed for flat ribbon cables with a 1.27mm (0.050 inch) pitch. Key specifications include a natural color housing, tin-plated contacts, and a closed-end design. The component is currently active and complies with RoHS3 standards.

Headers, Male Pins Feature Summary

• IDC termination mechanism compatible with 1.27mm pitch flat ribbon cables
• Through-hole mounting configuration for secure PCB integration
• Closed-end housing structure providing defined connection boundaries

Headers, Male Pins Applications

• Flat ribbon cable interconnections in consumer electronics assemblies
• Signal transmission between circuit boards using IDC interfaces
• Internal wiring connections within electronic devices requiring compact headers

Headers, Male Pins Procurement Notes

Verify the specific part number suffix to confirm the exact contact plating and housing material variant intended for your application. Ensure that the mating flat ribbon cable matches the required 1.27mm pitch specification to guarantee proper IDC engagement. Confirm compliance requirements such as RoHS3 status align with your manufacturing regulations before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 6-position IDC header is required for connecting 1.27mm pitch flat cables to a PCB via through-hole mounting. The 2.50mm spacing on the board side dictates the available layout area. Consider the closed-end design if complete row coverage is necessary without exposed pins at the ends of the connector strip.

Headers, Male Pins Part Context

This connector belongs to the CI22 series manufactured by Cvilux USA, a supplier specializing in connectors, FFCs, and wire harnesses primarily for consumer electronics. The series offers various configurations for wire-to-board applications, utilizing different termination methods and spacings to suit diverse assembly needs within electronic product designs.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify mechanical compatibility and electrical ratings with alternative suppliers if sourcing this specific Cvilux part is not feasible.
