CI2502P1H00-NH

Headers, Male Pins Overview

The CI2502P1H00-NH is a 2-position wire-to-board connector header from the Cvilux CI25 series. It features a 2.50mm (0.098 inch) mating pitch and utilizes through-hole, right-angle mounting for secure PCB attachment. The connector employs male pin contacts with circular terminal shapes and tin plating to ensure reliable signal transmission. Designed for board-to-cable or board-to-wire applications, it includes a four-wall shroud for alignment and protection. The unit operates within a temperature range of -25°C to 85°C and carries UL94 V-0 flammability ratings.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting design for stable PCB integration
• Four-wall shroud structure providing precise cable alignment and protection
• Tin-plated circular male pins ensuring durable electrical connectivity
• Halogen-free polyamide insulation material meeting UL94 V-0 standards

Headers, Male Pins Applications

• Consumer electronics internal wiring connections
• Industrial control system circuit boards
• Automotive electronic module interconnects
• Home appliance mainboard assemblies

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required pin count and pitch specifications before ordering. Confirm compliance with RoHS3 directives if environmental regulations apply to the project. Ensure the selected variant supports the intended current rating and voltage requirements for the specific application environment. Cross-reference the manufacturer datasheet for accurate mechanical dimensions to guarantee proper fit within the enclosure design.

Headers, Male Pins Selection Notes

Choose this component when a low-profile, right-angle connection is necessary for space-constrained designs. The 2.50mm pitch offers a balance between density and ease of assembly compared to finer pitches. Consider the through-hole termination method for robust mechanical strength in vibration-prone environments. Evaluate the operating temperature range to ensure compatibility with the thermal profile of the final product assembly.

Headers, Male Pins Part Context

This connector belongs to the CI25 series, which focuses on compact wire-to-board solutions. The series is characterized by its halogen-free materials and standardized 2.50mm spacing. It serves as a fundamental interconnect element in various electronic assemblies where reliable signal transfer and mechanical stability are prioritized over high-power handling capabilities.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain the 2.50mm pitch, 2-position configuration, and right-angle through-hole form factor. Verify that alternative headers share compatible shroud designs and contact plating specifications to ensure mating compatibility with existing cables and PCB footprints.
