CI2502P1V00-LF

CI2502P1V00-LF is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Cvilux USA. Its product description is 2 POS 2.50MM (.098) WIRE TO BOAR. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for CI2502P1V00-LF

• Description：2 POS 2.50MM (.098) WIRE TO BOAR
• Series：CI25
• Mfr：Cvilux USA
• Package：Bag
• Connector Type：Header
• Contact Type：Male Pin
• Pitch - Mating：0.098" (2.50mm)
• Number of Positions：2
• Number of Rows：1
• Row Spacing - Mating：-
• Number of Positions Loaded：All
• Style：Board to Cable/Wire
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Through Hole
• Termination：Solder
• Fastening Type：Detent Lock
• Contact Length - Mating：-
• Contact Length - Post：0.134" (3.40mm)
• Overall Contact Length：0.350" (8.89mm)
• Insulation Height：0.232" (5.90mm)
• Contact Shape：Circular
• Contact Finish - Mating：Tin
• Contact Finish Thickness - Mating：120.0µin (3.05µm)
• Contact Finish - Post：Tin
• Contact Material：Brass
• Insulation Material：Polyamide (PA46), Nylon 4/6
• Features：-
• Operating Temperature：-25°C ~ 85°C
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Natural
• Current Rating (Amps)：3A
• Voltage Rating：50VAC

Headers, Male Pins datasheet and documents for CI2502P1V00-LF
