CI2502P1V00-NH

Headers, Male Pins Overview

The CI2502P1V00-NH is a rectangular header connector manufactured by Cvilux USA, designed for through-hole PCB mounting. It features two positions with a 2.50mm (0.098 inch) pitch and male pin contacts. The housing is constructed from halogen-free polyamide (PA6T/Nylon 6T) glass-filled material, rated UL 94 V-0 for flammability. Electrical specifications include a current rating of 3A and a voltage rating of 250V. The operating temperature range spans from -25°C to 85°C.

Headers, Male Pins Feature Summary

• Halogen-free insulation material construction
• Through-hole mounting configuration
• Male pin contact type

Headers, Male Pins Applications

• General electronic circuit interconnections
• PCB-to-wire assembly applications
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify the specific suffix 'NH' confirms halogen-free compliance and PA6T insulation material as documented in official datasheets. Confirm that the part number corresponds to the straight header variant rather than right-angle or surface mount versions. Ensure compatibility with mating receptacles sharing the 2.50mm pitch standard. Cross-reference manufacturer documentation for precise mechanical dimensions and plating thickness requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a two-position through-hole header with 2.50mm spacing is required. Ensure the design accommodates the specified 3A current capacity and 250V voltage rating. Verify that the operating environment remains within the -25°C to 85°C temperature range. Confirm that the PCB layout supports the necessary hole size and pitch for reliable wave soldering or manual insertion processes.

Headers, Male Pins Part Context

This part belongs to the CI25 series of rectangular connectors from Cvilux USA. It shares the 2.50mm pitch family with variants offering different position counts and mounting styles. The 'NH' suffix typically denotes halogen-free material composition, distinguishing it from standard plastic variants. It serves as a basic interconnect solution within the broader portfolio of board-to-board and wire-to-board connector systems.

Headers, Male Pins Replacement Considerations
