CI2503P1H00-LF

Headers, Male Pins Overview

The CI2503P1H00-LF is a 3-position wire-to-board header connector from the Cvilux CI25 series. It features a 2.50mm (0.098 inch) pin spacing and utilizes through-hole, right-angle mounting for secure PCB attachment. The connector employs male pins with a circular contact shape and a four-wall shielded housing. Rated for 3A current and 250VAC voltage, it operates within a temperature range of -25°C to 85°C. The contacts are made of brass with tin plating, while the insulation consists of halogen-free PA6T reinforced with glass fiber, meeting UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Right-angle through-hole design ensures stable board-to-wire connections
• Four-wall shielded housing provides comprehensive electrical isolation
• Halogen-free PA6T insulation material supports environmental compliance

Headers, Male Pins Applications

• Automotive hybrid, electric, and powertrain systems
• Consumer electronics internal wiring
• General industrial control circuit interconnections

Headers, Male Pins Procurement Notes

Verify that the specific part number includes the LF suffix to confirm lead-free compliance status. Ensure the required pin count matches the three-position configuration. Confirm that the right-angle orientation aligns with the mechanical layout constraints of the target printed circuit board assembly.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for signal or low-power applications. The 2.50mm pitch offers a balance between density and ease of handling. Consider the 3A rating limit for current carrying capacity and ensure the operating environment remains within the specified thermal range for reliable performance.

Headers, Male Pins Part Context

This connector belongs to the CI25 series, which focuses on compact wire-to-board solutions. The series is designed for consumer electronics and general industrial applications requiring reliable interconnects. The manufacturer specializes in connectors, FFC cables, and wire harnesses for various electronic sectors.

Headers, Male Pins Replacement Considerations

The CI2503P1H00-NH serves as a direct substitute within the same series. Verify that the non-LF variant meets all environmental and regulatory requirements for the intended application before substitution.

Headers, Male Pins FAQ

What is the maximum rated voltage for this connector?

The CI2503P1H00-LF has a rated voltage of 250VAC.

Does the connector housing provide shielding?

Yes, the connector features a four-wall shielded housing design.
