CI3103P1V00-NH

Headers, Male Pins Overview

The CI3103P1V00-NH is a male pin header connector from the Cvilux USA CI31 series, designed for wire-to-board applications. It features a 3-position configuration with a 2.54mm (0.100 inch) pitch. The housing is constructed from polyamide (PA66), offering a white color and free-hanging installation type. Contacts utilize a solder termination method and are rated for operation between -25°C and 85°C. This component includes a friction lock fastening mechanism to secure mating connections.

Headers, Male Pins Feature Summary

• Male pin header design for reliable wire-to-board interconnections
• Friction lock fastening system ensures secure mating engagement
• Polyamide insulation provides durability across standard operating temperatures

Headers, Male Pins Applications

• Automotive hybrid systems
• Electric vehicle powertrain assemblies
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify that the specific part number suffix matches the required contact plating and housing variant. Confirm that the friction lock feature aligns with the assembly requirements. Ensure compatibility with the corresponding receptacle housing, such as the CI3103S0000, for proper mating. Check RoHS3 compliance status if environmental regulations apply to the final product integration.

Headers, Male Pins Selection Notes

Select this component when a male header with a 2.54mm pitch is required for board-level connections. The CI31 series offers a balance of mechanical stability and electrical performance. Consider the solder termination style for through-hole PCB mounting. Evaluate the 3-position count against circuit density needs. The free-hanging design allows for flexible orientation during assembly.

Headers, Male Pins Part Context

This connector belongs to the CI31 series, which focuses on general-purpose rectangular connectors. The series supports various position counts and termination styles. Cvilux USA manufactures these components for diverse electronic industries. The CI31 line emphasizes robust mechanical locking and consistent electrical contact reliability.

Headers, Male Pins Replacement Considerations

Direct substitutes include the 0050579503 from Molex. Verify pitch, position count, and locking mechanism compatibility before substitution.
