CI3303P1V10

Headers, Male Pins Overview

The CI3303P1V10 is a header connector manufactured by Cvilux USA, designed for through-hole mounting. It features a single row of male pins with three positions. The pitch between contacts is 0.100 inches (2.54mm). This component is intended for use in electronic assemblies requiring reliable signal or power connections.

Headers, Male Pins Feature Summary

• Through-hole mounting technology for secure board attachment
• Single row configuration with male pin contacts
• Standard 2.54mm pitch spacing for compatibility

Headers, Male Pins Applications

• Consumer electronics assembly
• IT and communication equipment
• Entertainment industry hardware

Headers, Male Pins Procurement Notes

Verify the exact part number against official Cvilux documentation to ensure correct pin count and pitch specifications. Confirm that the through-hole package type matches your PCB design requirements. Check for any specific RoHS compliance certifications if required by your manufacturing standards. Ensure the supplier is an authorized distributor to guarantee product authenticity.

Headers, Male Pins Selection Notes

Select this component when a 3-position, 2.54mm pitch header is required for through-hole applications. Consider the mechanical stability provided by the through-hole design compared to surface mount alternatives. Evaluate the current rating and voltage specifications against your circuit requirements before finalizing the selection.

Headers, Male Pins Part Context

Cvilux specializes in connectors, FFC cables, and wire harnesses primarily for consumer electronics, IT, and entertainment sectors. The CI3303P1V10 belongs to their range of header connectors, which are fundamental components for establishing electrical connections on printed circuit boards within these industries.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided data. When seeking replacements, ensure the alternative matches the 3-position count, 2.54mm pitch, and through-hole mounting style. Verify that the replacement header maintains compatible mechanical dimensions and electrical characteristics.
