CI4403M1VR0-NH

Headers, Male Pins Overview

The CI4403M1VR0-NH is a single-row male pin header manufactured by Cvilux USA, designed for surface-mount board-to-cable or wire applications. It features a 3-position configuration with a 0.049-inch (1.25mm) pitch. The connector utilizes phosphor bronze contacts with tin plating and PA6T insulation rated UL94 V-0. It operates within a temperature range of -40°C to 85°C, supporting 1A current at 125VAC.

Headers, Male Pins Feature Summary

• Surface-mount installation style for automated assembly
• Three-wall shielded housing design
• Solder retention feature for secure PCB attachment

Headers, Male Pins Applications

• Automotive electronic systems
• Board-to-cable interconnections
• Wire-to-board assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against manufacturer documentation to confirm package type and termination style. Ensure compatibility with mating housings from the same series. Confirm RoHS3 compliance status through official datasheets before procurement. Cross-reference part numbers with authorized distributors to avoid counterfeit components.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount header is required for tight spatial constraints. The 1.25mm pitch suits high-density circuit designs. Verify that the 1A current rating meets system requirements. Consider the natural color and PA6T material for environmental resistance.

Headers, Male Pins Part Context

This part belongs to the CI44 series of rectangular connectors. It pairs with corresponding receptacle housings such as the CI4403S0000-NH. The series offers various position counts and mounting styles for diverse connectivity needs.

Headers, Male Pins Replacement Considerations

Direct substitutes include CI4403M1HR0-NH for right-angle surface mount configurations.
