CI6303M2VR0-NH is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Cvilux USA. Its product description is 3 POS 1.20MM(.048) WIRE TO BOARD. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for CI6303M2VR0-NH
- Description：3 POS 1.20MM(.048) WIRE TO BOARD
- Series：CI63
- Mfr：Cvilux USA
- Package：Tape & Reel (TR),Cut Tape (CT)
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.059" (1.50mm)
- Number of Positions：3
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 3 Wall
- Mounting Type：Surface Mount
- Termination：Solder
- Fastening Type：Friction Lock
- Contact Length - Mating：-
- Contact Length - Post：-
- Overall Contact Length：-
- Insulation Height：0.057" (1.45mm)
- Contact Shape：Rectangular
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：Tin
- Contact Material：Phosphor Bronze
- Insulation Material：Polyamide (PA6T), Nylon 6T, Halogen Free
- Features：Solder Retention
- Operating Temperature：-
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：-
- Voltage Rating：-
Headers, Male Pins datasheet and documents for CI6303M2VR0-NH
Headers, Male Pins Overview
The CI6303M2VR0-NH is a surface mount rectangular connector header manufactured by Cvilux USA. It features a single row of three positions with a pitch of 0.059 inches (1.50mm). The housing is constructed from flame-retardant material rated UL94V-0, ensuring safety compliance in electronic assemblies. This component is designed for free-hanging installation and utilizes friction lock retention mechanisms to secure mating connections.
Headers, Male Pins Feature Summary
- Surface mount technology design for automated PCB assembly processes
- Single row configuration providing compact spatial efficiency
- Flame retardant housing construction meeting UL94V-0 standards
Headers, Male Pins Applications
- Consumer electronics internal interconnections
- Computer peripheral hardware interfaces
- General purpose board-to-board signal transmission
Headers, Male Pins Procurement Notes
Verify the specific ordering suffix against the manufacturer's current datasheet to ensure compatibility with required contact plating and terminal specifications. Confirm that the selected variant matches the intended surface mount footprint dimensions and thermal profile requirements for your manufacturing process before finalizing procurement orders.
Headers, Male Pins Selection Notes
Select this component when a low-profile, surface mount header is required for high-density circuit layouts. Ensure the mating connector aligns with the 1.50mm pitch specification. Consider the UL94V-0 rating if fire safety certifications are mandatory for the end product application environment.
Headers, Male Pins Part Context
This part belongs to the CI63 series of rectangular connectors produced by Cvilux USA. The series focuses on precision electronic connectors suitable for consumer electronics and computer applications. The manufacturer specializes in high-precision components including FFC cables and wire harnesses alongside these connector systems.
Headers, Male Pins Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify mechanical compatibility and electrical ratings before considering alternative manufacturers.
