CL2-F30-12R

Power Line Filter Modules Overview

The CL2-F30-12R is a single-phase EMC/EMI line filter module manufactured by DIT (Dong Il Technology Ltd). It is designed for power line noise suppression in AC and DC circuits. The component features a single-stage configuration with a current rating of 3 A and voltage ratings of 250 VAC and 250 VDC. It operates at frequencies of 50 to 60 Hz and utilizes quick connect terminals for installation.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference (EMI) and radio frequency interference (RFI) suppression for single-phase power lines.
• Utilizes a single-stage filtering architecture to attenuate conducted noise.
• Equipped with quick connect terminals for straightforward circuit integration.

Power Line Filter Modules Applications

• Single-phase AC power line noise filtering
• DC power supply input filtering
• General electronic equipment EMI suppression

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation as Dong Il Technology Ltd (DIT) when sourcing this component. Confirm that the specific part number CL2-F30-12R matches the required 3 A current rating and 250 VAC/VDC voltage specifications. Ensure compatibility with quick connect terminal interfaces before procurement.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-stage noise attenuation in single-phase systems. Ensure the operating environment supports the specified 250 VAC and 250 VDC limits. Verify that the 3 A current capacity meets the load requirements and that the quick connect mounting style fits the available PCB or wiring harness design.

Power Line Filter Modules Part Context

This component belongs to the CL series of power line filter modules from DIT. These filters are engineered for general-purpose electromagnetic compatibility improvements in low-power electronic devices. The series typically offers compact solutions for integrating noise suppression directly into power entry points without requiring complex multi-stage designs.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify pinout and electrical characteristics carefully if considering alternative manufacturers, as mechanical dimensions and terminal types may differ significantly between suppliers.
