CL2-F45-12R

Power Line Filter Modules Overview

The CL2-F45-12R is a single-phase EMC/EMI line filter module manufactured by DIT. It is designed for chassis mounting and supports AC/DC voltages up to 250VAC/VDC with a rated current of 4.5A. The unit operates at frequencies between 50Hz and 60Hz. It features a single-stage filtering architecture intended to suppress electromagnetic interference in power lines.

Power Line Filter Modules Feature Summary

• Single-phase EMI/EMC filtering capability
• Chassis mount construction
• Supports 250VAC/VDC input ratings

Power Line Filter Modules Applications

• Industrial equipment power supply protection
• Medical device power line filtering
• General electronic apparatus noise suppression

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation, as DIT may refer to Dong Il Technology or Dit Messtechnik GmbH depending on the specific component lineage. Confirm that the 4.5A rating and 250VAC/VDC specifications match the system requirements. Ensure the chassis mount form factor fits the enclosure design. Check for any specific certification marks required for the target market.

Power Line Filter Modules Selection Notes

Select this model when a single-stage solution is sufficient for the application's noise profile. Compare leakage current specifications against safety standards if used in medical or sensitive environments. Ensure the operating temperature range meets the environmental conditions. Verify that the physical dimensions allow for proper heat dissipation and mounting clearance.

Power Line Filter Modules Part Context

This component belongs to the CL2-F series of line filters. Similar models in the series include variants with different current ratings such as the CL2-F30-12R or CL2-F60-12R. These units share common design principles for single-phase power line interference suppression but differ in their maximum current handling capabilities.

Power Line Filter Modules Replacement Considerations

Direct substitutes may include other single-phase chassis-mount filters with identical 4.5A and 250VAC ratings. Verify pinout compatibility and mounting hole patterns before replacing. Cross-reference with Dong Il Technology equivalents if available.
