CL2-F60-12R

Power Line Filter Modules Overview

The CL2-F60-12R is a miniature general-purpose power line filter module manufactured by DIT (Dong Il Technology). Designed for chassis mounting, this EMC/EMI filter supports a continuous current of 6A and operates at voltages up to 250VAC/VDC. The unit features a plastic case with a metal cover, providing robust shielding against electromagnetic interference. It is engineered for noise suppression in electronic circuits requiring reliable filtering performance within a compact form factor.

Power Line Filter Modules Feature Summary

• Miniature general-purpose design with a plastic case and metal cover
• Chassis mount configuration for secure installation
• EMC/EMI noise filtering capability

Power Line Filter Modules Applications

• Electronic equipment requiring EMI/EMC compliance
• Power supply input filtering
• Chassis-mounted circuit protection

Power Line Filter Modules Procurement Notes

Verify the manufacturer part number CL2-F60-12R against official DIT documentation to ensure authenticity. Confirm that the specified 6A rating and 250VAC/VDC voltage limits align with your system requirements. Check for any specific ordering suffixes or variations that may affect compatibility. Ensure the chassis mount style matches your enclosure design constraints before finalizing procurement.

Power Line Filter Modules Selection Notes

Select this component when a compact, chassis-mountable EMI filter is required for 6A applications. The metal cover provides necessary shielding for sensitive electronics. Ensure the operating voltage does not exceed 250VAC/VDC. Verify physical dimensions fit the designated chassis space. Consider the general-purpose nature of the filter for standard noise reduction needs rather than specialized high-frequency or high-voltage isolation tasks.

Power Line Filter Modules Part Context

The CL2-F60-12R belongs to the CL2-F series of line filter modules from DIT. This series offers various current ratings and configurations for different power line filtering needs. The CL2-F60-12R specifically addresses the 6A requirement within this lineup, utilizing a standardized chassis mount format common in industrial and commercial electronic assemblies for effective electromagnetic interference mitigation.

Power Line Filter Modules Replacement Considerations

Consult DIT's official cross-reference data for direct substitutes. Ensure any replacement maintains the 6A current rating and 250VAC/VDC voltage specification. Verify that the chassis mount footprint and terminal configuration are compatible with existing PCB or panel layouts. Do not assume functional equivalence based solely on similar part numbers without verifying technical parameters.
