CL4532A-201

$1.70

Description：CHIP LAN XFMR 10/100/1000 BASE-T
Series：-
Mfr：Mentech Technology USA Inc.
Package：Tape & Reel (TR)

SKU:55dccbe0402d Category: Pulse Transformers Brand: Mentech Technology USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CHIP LAN XFMR 10/100/1000 BASE-T
Series：-
Mfr：Mentech Technology USA Inc.
Package：Tape & Reel (TR)
Transformer Type：LAN 10/100/1000 Base-T
Inductance：200µH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1CT:1CT
Mounting Type：Surface Mount
Size / Dimension：0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max)：0.138" (3.50mm)
Operating Temperature：0°C ~ 70°C
Grade：-
Qualification：-

Download product information

CL4532A-201

Overview

The CL4532A-201 is a surface-mount pulse transformer manufactured by Mentech Technology USA Inc., designed for LAN applications supporting 10/100/1000 Base-T standards. It features an inductance of 200µH and a turns ratio of 1CT:1CT. The component operates within a temperature range of -40°C to +85°C. Its physical dimensions are 4.5mm in length and 3.2mm in width, with a weight of approximately 0.15g. The device is currently active and suitable for high-speed Ethernet data transmission.

Feature Summary

Optimized for 10/100/1000 Base-T Ethernet applications
Surface mount construction for automated assembly
Compact footprint suitable for space-constrained designs

Applications

Gigabit Ethernet network interfaces
Computer motherboard LAN ports
Network interface cards (NICs)
Industrial communication equipment

Procurement Notes

Verify the specific datasheet version A0 issued on 2020/04/01 for precise electrical characteristics. Confirm that the 1CT:1CT configuration matches the circuit design requirements. Ensure compatibility with the specified operating temperature range of -40°C to +85°C during system integration.

Selection Notes

Select this component when a compact, surface-mount solution is required for Gigabit Ethernet PHY interfaces. The 200µH inductance value supports high-frequency signal integrity. Consider the 4.5mm x 3.2mm package size for PCB layout constraints. Verify insulation voltage ratings if isolation requirements exceed standard specifications.

Part Context

This part belongs to the pulse transformer category from Mentech Technology USA Inc. It is specifically engineered for local area network connectivity. The product status is listed as active, indicating ongoing manufacturing support. It serves as a critical passive component in modern networking hardware.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult official distributor databases for cross-reference information before replacing this component in existing designs.
