Product Detailed Parameters
- Description：CMC 1MH 500MA 2LN SMD
- Series：CLJ-2
- Mfr：Amgis, LLC
- Package：Tape & Reel (TR)
- Filter Type：-
- Number of Lines：2
- Current Rating (Max)：500mA
- DC Resistance (DCR) (Max)：275mOhm (Typ)
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-25°C ~ 85°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Surface Mount
- Size / Dimension：0.350" L x 0.213" W (8.90mm x 5.40mm)
- Height (Max)：0.146" (3.70mm)
- Package / Case：Horizontal, 4 Flat Lead
- Inductance @ Frequency：1 mH @ 100 kHz
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The CLJ-2-102 is a surface-mount common mode choke manufactured by Amgis, LLC. It features an inductance of 1 mH measured at 100 kHz and supports a maximum current rating of 500 mA. The device exhibits a typical DC resistance (DCR) of 275 mOhm. Designed for two-line applications, it utilizes a surface mount package with four flat leads.
Feature Summary
- Provides common mode noise suppression for dual-line circuits
- Engineered for surface mount technology integration
- Utilizes a compact form factor suitable for space-constrained designs
Applications
- Signal line filtering in electronic equipment
- Noise suppression in data transmission interfaces
- EMI reduction in power supply input stages
Procurement Notes
Verify the specific datasheet version to confirm lead frame material and terminal plating specifications. Ensure the selected component matches the required impedance tolerance and current saturation characteristics for the target circuit design before finalizing procurement orders.
Selection Notes
Select this component when a low-profile surface mount solution is required for differential signal integrity. Evaluate the 500 mA current rating against peak load requirements. Confirm that the 275 mOhm DCR aligns with system power loss constraints and thermal management capabilities.
Part Context
This component belongs to the CLJ-2 series of common mode chokes from Amgis, LLC. The series offers various inductance values optimized for high-frequency noise attenuation. These devices are designed to replace through-hole alternatives in modern automated assembly processes.
Replacement Considerations
Direct substitutes may include other surface mount common mode chokes with matching 1 mH inductance and 500 mA current ratings. Verify footprint compatibility and electrical parameters such as DCR and impedance curves before substitution.
FAQ
What is the test frequency for the specified inductance?
The inductance value of 1 mH is specified at a test frequency of 100 kHz.
How many lines does this choke support?
The CLJ-2-102 is designed for two-line applications.
