Product Detailed Parameters
- Description：LED RED 4PLCC SMD
- Series：CLM2C-RCA/ACA
- Mfr：Cree LED
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Red
- Configuration：Standard
- Lens Color：-
- Lens Transparency：-
- Millicandela Rating：3500mcd
- Lens Style：Round with Domed Top
- Lens Size：2.45mm Dia
- Voltage - Forward (Vf) (Typ)：2V
- Current - Test：20mA
- Viewing Angle：-
- Mounting Type：Surface Mount
- Wavelength - Dominant：622nm
- Wavelength - Peak：-
- Features：-
- Package / Case：4-PLCC
- Supplier Device Package：4-PLCC
- Size / Dimension：3.20mm L x 2.80mm W
- Height (Max)：3.86mm
- Grade：-
- Qualification：-
Download product information
Overview
The CLM2C-RCA-CWBZ0BB3 is a single-color red surface-mount LED from Cree LED, designed for high-reliability applications. It features a PLCC-4 package with dimensions of 3.2mm x 2.8mm. The component emits light at a dominant wavelength of 622nm with a luminous intensity of 3.5cd. Electrical specifications include a forward current of 20mA and a forward voltage of 2V. The lens is black with a non-diffused dome shape, suitable for precise optical control in compact designs.
Feature Summary
- Compact PLCC-4 SMD form factor optimized for space-constrained layouts
- High-reliability performance suitable for demanding lighting environments
- Black lens design enhances contrast and visual definition
Applications
- Channel letter signage
- Architectural lighting
- Commercial downlights
Procurement Notes
Verify the specific suffix CWBZ0BB3 against official Cree LED documentation to confirm exact binning and optical characteristics. Ensure compatibility with standard SMT reflow profiles. Check regional availability as distribution status may vary by location. Confirm RoHS compliance details through the manufacturer's latest datasheet before finalizing procurement plans.
Selection Notes
Select this component when a small footprint and high reliability are required for red indication or illumination. The 20mA forward current rating aligns with standard driving circuits. Consider the 622nm wavelength for specific color rendering needs. The PLCC-4 package offers ease of assembly compared to larger arrays while maintaining robust thermal performance.
Part Context
This part belongs to the CLM2C series of Cree LED single-color SMD LEDs. The series includes variants like CLM2C-ACA for amber options. These components are engineered for architectural and signage uses, offering a balance between size and brightness. The PLCC-4 package is a common industry standard for surface-mount LED applications.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Verify pinout and thermal requirements if considering alternative manufacturers. Cross-reference electrical parameters such as forward voltage and current limits to ensure circuit compatibility without direct substitution data.
