CLMWB-FKA-CDE1HJ1A1BB7C4R3

Overview

The CLMWB-FKA-CDE1HJ1A1BB7C4R3 is a PLCC-4 surface-mount RGB LED from Cree LED. It features a water-resistant IPX8 rating and a round flat lens with a 2.4 mm diameter. The component measures 3.2 mm in length, 2.80 mm in width, and has a maximum height of 1.70 mm. Electrical parameters include a forward current of 20 mA per channel. Forward voltages are specified at 1.9 V for red, 3 V for green, and 3 V for blue. Wavelengths are 622 nm (red), 530 nm (green), and 470 nm (blue). Luminous intensity values are 148 mcd, 295 mcd, and 74 mcd respectively.

Feature Summary

• IPX8 water-resistant rating for durability in wet environments
• Integrated RGB configuration within a compact PLCC package
• Diffused lens design providing a wide viewing angle

Applications

• Waterproof indicator lighting
• Outdoor electronic displays
• Marine instrumentation panels

Procurement Notes

Verify the specific suffix against official datasheets to ensure correct optical and electrical characteristics. Confirm moisture sensitivity level (MSL) handling requirements during storage and assembly. Check RoHS compliance status and lead times with authorized distributors prior to ordering.

Selection Notes

Select this component when waterproofing is required for SMD RGB applications. Ensure the PLCC-4 footprint matches the PCB layout. Verify that the 120-degree viewing angle meets visibility needs. Compare luminous intensity requirements against the specific color channels provided.

Part Context

This part belongs to the CLMWB series of high-performance tricolor LEDs. The series is designed to simplify designs and lower system costs. It offers reliable performance in demanding environments due to its sealed construction.

Replacement Considerations

CLVBA-FKA-CA1D181BB7R3R3

FAQ

What is the sealing rating of this LED?

The component features an IPX8 water-resistant rating.

What is the package type?

It utilizes a PLCC-4 surface-mount package.
