Product Detailed Parameters
- Description：DATA LINE FILTER, 8 FUNCTION(S),
- Series：*
- Mfr：onsemi
- Package：Bulk
- Type：-
- Filter Order：-
- Technology：-
- Number of Channels：-
- Center / Cutoff Frequency：-
- Attenuation Value：-
- Resistance - Channel (Ohms)：-
- Values：-
- ESD Protection：-
- Operating Temperature：-
- Applications：-
- Voltage - Rated：-
- Mounting Type：-
- Package / Case：-
- Size / Dimension：-
- Height：-
- Current：-
- Grade：-
- Qualification：-
Download product information
Overview
The CM1454-08CP is an 8-channel EMI/RFI filter array manufactured by onsemi, designed for mobile device data lines. It utilizes a hybrid LC and RC network topology, specifically comprising three C-L-C sections and five C-R-C sections. The component provides integrated electrostatic discharge (ESD) protection alongside signal filtering. It operates within a temperature range of -40°C to +85°C and is housed in a compact surface-mount package.
Feature Summary
- Integrates eight independent channels for simultaneous data line protection
- Combines LC and RC filtering topologies for enhanced noise suppression
- Provides built-in ESD protection capabilities
- Designed for high-density surface-mount applications
Applications
- Mobile device data lines
- Portable electronics signal interfaces
- High-speed data port protection
Procurement Notes
Verify current availability status as the part may be discontinued or subject to specific ordering requirements. Confirm exact packaging specifications and lead times directly with authorized distributors or the manufacturer. Ensure compatibility with existing PCB footprints and thermal management strategies before finalizing procurement decisions.
Selection Notes
Select this component when multiple data lines require combined ESD protection and EMI filtering in a single footprint. The hybrid LC/RC structure offers flexibility for different impedance matching needs across various channels. Consider the 20-WFBGA/WLCSP package size constraints and operating temperature range relative to the target application environment.
Part Context
This component belongs to onsemi's portfolio of EMI/RFI filters intended for consumer electronics. It addresses the increasing need for robust signal integrity and protection in compact mobile devices. The design supports the miniaturization trends in modern hardware while maintaining effective noise reduction standards for sensitive data interfaces.
Replacement Considerations
Consult official substitution guides for compatible alternatives. Verify pinout compatibility and electrical parameter equivalence if considering cross-references from other manufacturers.
